JVS-N819-ZDL 4K 8.0MP Motorized Zoom Camera
-Full-Color Night Vision & 80m IR
The JVS-N819-ZDL is a professional 4K 8.0MP motorized zoom camera featuring 24/7 full-color recording, 80m IR distance, built-in audio, and VQC technology for superior surveillance.
Shipping calculated at checkout.
Guarantee Safe and Secure Payment Checkout
- Motorized Varifocal Lens (2.7~13.5mm) for Easy Installation and Monitoring
- 24/7 Full-Color
- Built-in Mic and Speaker
- With VQC Technology
- Support SD Card (Up to 512GB)
- WDR (120dB)
| Video | |
| Image Sensor | 1/3″ CMOS |
| Max Resolution | 3840×2160 |
| Effective Pixels | 8.0MP |
| Compression Standard | H.264/H.265+ |
| Framerate | 30fps |
| Bitrate | Main Stream: 256Kbps ~ 4096Kbps
Sub Stream: 68Kbps~1024Kbps Third Stream: 68Kbps~1028Kbps |
| SNR (dB) | ≥50dB |
| Min. Illumination | 0Lux (light ON) |
| Lens | |
| Lens | Varifocal Lens, Motorized Lens, 2.7mm-13.5mm |
| FOV | Horizontal FOV: 101.4° to 26.9°
Vertical FOV: 53.6° to 15.2° Diagonal FOV: 118.7° to 30.5° |
| Function | |
| Audio Codec | G.711U/G.711A (Default) |
| Exposure Control | Auto |
| White Balance | Auto |
| Gain Control | Auto |
| Digital 3D Noise  Reduction | Support |
| OSD Information Setting | By default: The customized OSD supports a maximum of six lines, each line contains a maximum of 32 characters. One Chinese character is counted as two characters |
| SNTP | Support |
| Schedule Reboot | Support |
| Smart Defog | Support |
| Smart Motion Detection | Not Support |
| Image Setting | Support Saturation, Brightness, Contrast, Sharpness adjustment |
| Image Style | Standard, Soft, Transparent |
| Day and Night Function | Auto, Always Black & White, Always Color, Scheduled Color |
| Privacy Mask | Support up 8 areas |
| Night Vision Optimization | Support |
| WDR | 120dB |
| Screen Settings | Screen mirroring, Screen flipping |
| IP Adaptation | Support automatic adaptation of IP address (Optional) |
| Intelligent  Analysis | Not Support |
| Alarm Method | Email Alarm, Client Alarm |
| Remote Operation | System, Audio and Video, Image, Alarm, Network management, Storage management, Intelligent Analysis |
| Audio Function | Built-in Mic and Speaker |
| SD Card | Support(512GB) |
| Peripheral  Extension Interface | Audio Input/Output, Alarm Input/Output |
| Network | |
| Ethernet | 10/100Mbps Ethernet |
| Stream | 3x  Streams |
| Network Protocols | HTTP, TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS |
| Access Protocol | Standard ONVIF, Public Cloud |
| Network Transmission | CloudSEE 2.0 |
| Fusion Cloud  Platform | Support |
| Browser | IE8+, Chrome18+, Firefox5.0+, Safari5.02+ |
| User | Up  to 13 Users |
| App | Support iOS/Android |
| General | |
| Lights | 4 Warm Light LEDs + 4 IR LEDs |
| IR Distance | IR: Up to 80 MetersWarm Light: Up to 60 Meters |
| Waterproof Level | IP67 |
| Power Supply | DC12V/2A Â or PoE |
| Power Consumption | <6W (During Day); <12W (At Night) |
| Working Temperature | -30°C ~ +60°C |
| Working Humidity | 10% ~ 90% Rh |
| Color/Material | Black and White/Metal+Plastic |
| Dimensions (WxHxD) | 103x91x255mm |
| Weight | 732g |
| Installation Method | Wall or Ceiling Mount |
JVS-N819-ZDL 4K 8.0MP Motorized Zoom Camera with Full-Color Night Vision & 80m IR
Product Overview
The JVS-N819-ZDL represents cutting-edge surveillance technology with its 4K 8.0MP resolution and motorized varifocal lens (2.7-13.5mm). This advanced network camera delivers:
-
Ultra HD 3840×2160 resolution with H.265+ compression
-
Motorized zoom lens with 101.4° to 26.9° adjustable FOV
-
24/7 full-color imaging with dual illumination (4 warm light + 4 IR LEDs)
-
80m IR distance and 60m warm light coverage
-
Built-in microphone and speaker for two-way audio
-
VQC technology and 120dB WDR for optimal image quality
-
IP67 weatherproof metal housing for outdoor use
With triple streaming, 512GB SD storage, and ONVIF/CloudSEE 2.0 compatibility, the JVS-N819-ZDL excels in critical monitoring applications like perimeter security, large facilities, and smart city projects.
