JVS-ND7932-DV 32CH 4HDD H.265 NVR with 4K Output, VSmart Coding & Dual Network
-with 4K Output, VSmart Coding & Dual Network
The JVS-ND7932-DV is a 32-channel 4HDD H.265 NVR featuring 4K video output, VSmart coding, 40TB total storage, AI human detection, and dual network interfaces for advanced surveillance.
Shipping calculated at checkout.
Guarantee Safe and Secure Payment Checkout
Key Features
• 4K Video Output
• Adopt the new VStar GUI, easy to operate and run smoothly
• Support intelligent coding VSmart, greatly reducing storage space
• Improved compatibility for HDD. Support 4x SATA max. of 10TB
• Support Alarm-In and Alarm-Out. 6 Input and 1 Output.
• Support RS485
• Support Intelligent Detection and Human Detection
• Support dual Network Interface
| Model | JVS-ND7932-DV |
| Video & Audio | |
| IP Camera Input | 32 Channel |
| Audio Input/ Output | 1 Channel RCA Output, 1 Channel RCA Input32 Channel Audio output through HDMI |
| Bandwidth I/O | 320Mbps/160Mbps |
| Display | |
| Interface | 1 HDMI, 1 VGA |
| Video Output | HDMI: 3840×2160/ 2560×1440/ 1920×1080/ 1440×900/ 1280×1024/ 1280×720/ 1024×768 |
| VGA: 1920×1080/ 1440×900/ 1280×1024/ 1280×720/ 1024×768 | |
| Max Decoding | 32CH 5.0MP/ 4.0MP/ 1080p/ 960p/ 720p @25fps |
| Multi-Screen Display | 1/ 4/ 5/ 6 up to 32 |
| OSD | Camera Name & Time, Recording, Alarm Detecting, Remote connection,
Volume, Channel Number |
| Recording | |
| Compression | H.265/H.264 |
| Resolution | 32CH 5.0MP/ 4.0MP/ 1080p/ 960p/ 720p |
| Record Mode | Manual, Schedule, Motion Detection |
| Video Detection & Alarm | |
| Trigger Events | Recording, Snapshot, PTZ, Voice, E-mail, Client, Buzzer |
| Video Detection | Motion Detection, No Video Detection |
| Alarm-In & Out | 6CH Alarm Input; 1CH Alarm Output |
| Playback & Backup | |
| Sync Playback | 2CH 5.0MP / 3CH 4.0MP/ 3CH 3.0MP/ 4CH 1080p |
| Search Mode | Channel Number / Recording Type / Date |
| Playback Function | Day View, Hour View, Back Step, Rewind, Pause, Play, Fast Forward,
Slow, Step, Full Screen, Snap, Sound On/Off, Zoom |
| Backup Mode | FAT32 USB Device/ Network |
| Network & Interfaces | |
| Network Interface | 2x RJ45 (10/100/1000Mbps) |
| Network Function | TCP/IP, DHCP, UDP, SMTP, NTP, CloudSEE |
| Smart Phone | Support iOS, Android App |
| Interoperability | ONVIF 2.4 |
| PTZ Interface | RS485 |
| Storage | |
| SATA | 4 SATA Interface |
| Capacity | Up to 10TB |
| USB | 3x USB |
| General | |
| Power Supply | DC 12V |
| Consumption | ≤20W (Without HDD) |
| Working Temperature | -10°C ~ 55°C |
| Working Humidity | 10% ~ 90% |
| Dimensions | 445x45x320mm |
| Weight | ≤5Kg (Without HDD) |
JVS-ND7932-DV 32CH 4HDD H.265 NVR with 4K Output, VSmart Coding & Dual Network
Product Overview
The JVS-ND7932-DV is a high-capacity 32-channel H.265 network video recorder designed for enterprise-level surveillance applications. JVS-ND7932-DV supports up to 4 hard drives with 10TB capacity each, providing massive 40TB total storage with efficient VSmart coding technology that reduces bandwidth and storage requirements. This NVR delivers stunning 4K video output and incorporates advanced AI analytics including human detection and motion analysis for intelligent security monitoring. JVS-ND7932-DV features dual Gigabit network interfaces for enhanced connectivity and failover protection, 6 alarm inputs, 1 alarm output, and RS485 for PTZ control. With ONVIF 2.4 compliance for broad camera compatibility and user-friendly VStar GUI, the JVS-ND7932-DV offers enterprise-grade performance for large facilities, commercial complexes, and industrial sites requiring reliable, high-capacity surveillance with advanced features.
