JVS-ND9132-HZ | 32CH 8x SATA H.265 NVR
-with 4K Support & 80TB Storage
The JVS-ND9132-HZ is a 32CH 8x SATA H.265 NVR featuring 4K input/output, 80TB storage capacity, 16 alarm inputs, and enterprise-level surveillance management.
Shipping calculated at checkout.
Guarantee Safe and Secure Payment Checkout
Key Features
- Adopt the New Vstar GUI , Easy to Operate and Run Smoothly
- Support 4K Output
- Support 4K IP Cameras Input
- Support Audio Input and Output;
- Support Alarm Input and Output, 16 In 4 Out
- Support 8x SATA , Up to 10TB Each
- Support RS485
Specifications
| Model | JVS-ND9132-HZ |
| Video & Audio | |
| IP Camera Input | 32 Channel |
| Video Output | HDMI: 4K@60Hz/ 4K@30Hz/ 2K@60Hz/ 2K@30Hz/ 1920×1080/ 1440×900/ 1280×1024/ 1280×720/ 1024×768 |
| VGA: 1920×1080 | |
| Audio In & Out | Support |
| Compression | H.265/ H.264 |
| Max Decoding | 4K/5.0MP/4.0MP/1080P/960P/720P 30fps |
| Bandwidth I/O | 400Mbps/320Mbps |
| Storage | |
| SATA | 8x SATA Interface |
| Capacity | Up to 10TB Max. |
| File Format | Log: *.txt/ Picture: *.JPG/ Video: *.mp4 |
| Backup Mode | USB 3.0 Device FAT32/ NTFS/ exFAT |
| Video | |
| Video Playback | Auto/ Timing/ Alarm/ Motion Detection/ Intelligent Analysis |
| Sync Playback | 1ch 4K,2ch 5.0MP,3ch 4.0MP,4ch 3.0MP,4ch 1080P |
| Search Mode | Channel Number/ Recording Type/ Date |
| Network | |
| Ethernet | 100/1000Mbps |
| Network Function | TCP/IP, UDP/IP, CloudSEE, SMTP, NTP, DHCP |
| Interoperability | ONVIF 2.4, CloudSEE 2.0 |
| Smart Phone | iPhone, Android |
| Hardware | |
| Network Interface | 2x RJ45 |
| USB Interface | 3x USB2.0, 1xUSB3.0 |
| PTZ Interface | RS485 |
| Controlling Device | Mouse |
| Alarm Input | 16CH |
| Alarm Output | 4CH |
| Special | |
| Multi-Screen Display | 1/ 4/ 5/ 6 up to 32 |
| Alarm Method | Buzzer, Push to App, Email Alarm, External Alarm |
| Digital Zoom | Support |
| General | |
| Power Supply | ATX |
| Consumption | ≤ 30 W (Without HDD) |
| Working Temperature | -10°C ~ 55°C |
| Working Humidity | 10% ~ 90% |
| Dimensions | 445×90.5×430(mm) |
| Weight | ≤ 8Kg (Without HDD) |
JVS-ND9132-HZ | 32CH 8x SATA H.265 NVR with 4K Support & 80TB Storage
Product Overview
The JVS-ND9132-HZ is an enterprise-grade 32CH H.265 network video recorder designed for large-scale surveillance systems requiring massive storage and high-resolution processing. The JVS-ND9132-HZ supports up to 32 IP cameras with 4K resolution input and output capabilities, delivering exceptional video quality for critical monitoring applications. Featuring 8 SATA interfaces supporting up to 10TB each, this NVR offers massive 80TB total storage capacity for extended recording periods and high-resolution video retention. With advanced H.265 compression technology, dual network interfaces, and 400Mbps bandwidth handling, the JVS-ND9132-HZ ensures efficient operation even with multiple high-resolution cameras. The system includes 16 alarm inputs, 4 alarm outputs, RS485 PTZ control, and comprehensive network functionality including ONVIF 2.4 compliance. Ideal for large commercial facilities, industrial complexes, government installations.
