JVS-VS6836-S 36-Bay Video Storage Server – 720TB
– 720TB RAID & 850M Write Speed
The JVS-VS6836-S storage server features 36 hot-swappable bays (20TB/drive), 850M write speed, and RAID 60 support. Ideal for petabyte-scale surveillance archives with EMI shielding and auto-recovery.
Shipping calculated at checkout.
Guarantee Safe and Secure Payment Checkout
High Performance
- Powered by Intel X86 high performance multi-core processor.
- Supports DDR4 memory, standard 16GB, supports up to 32GB after expansion.
- Built-in 500G solid-state drive, the server can be equipped with 36 * 2.5-inch/3.5-inch hard drives, and a single drive supports 20TB capacity.
- Support media forwarding + video storage sharing 850M (or independent scene use).
High Stability
- Supports long-term storage of recording information with a maximum of 36 disk slots.
- Supports 850M data write.
- Supports RAID 0, 50, 60, and JBOD storage modes.
High Reliability
- Intelligent cooling system is used to effectively reduce noise pollution and create a constant temperature space in the box; fully shielded against electromagnetic radiation, anti-interference, and anti-static (EMI) design.
- Supports docking with different mainstream manufacturers’ management platforms through standard protocols such as IPSAN/NFS.
- Supports streaming media forwarding, alarm video storage, disk failure alarm, and automatic removal of faulty disks.
- Supports automatic reconnection of video when network is disconnected, etc.
| OS | Linux OS |
| CPU | Intel X86 High performance multi-core processor |
| Memory | 16G DDR4 memory, support expansion to 32G |
| System Drive | 500G SSD, supports power outage protection |
| Data Drive | Supports up to 36 SATA interfaces, and a single drive supports up to 10TB |
| Network Interface | 2 * RJ45 10/100/1000Mbps adaptive Ethernet ports |
| Network Protocol | RTMP, HLS, TCP/IP, Telnet, etc. |
| USB Port | A total of 4, Front: 2 * USB2.0 Port, Rear: 2 * USB2.0 Port |
| Display Interface | Front: 1 * Power Button, 1 * Restart Button, 1 * Hard Disk Indicator Light, 1 * System Fault Light, 2 * Network Indicator LightsRear: 1 * VGA, 1 * Management Network Port, 2 * RJ45 Network Ports |
| Power Supply | 100~240V AC, 1300W 1+1 redundant power supply |
| Power Consumption (Not Including Hard Drive) | ≤ 85W |
| Working Temperature | Working temperature: 0℃～+60℃, storage temperature: -25℃～+75℃ |
| Working Humidity | Working humidity: 10%~90%, Storage humidity: 5%~95%, non-condensing |
| Dimension | 4U size, Depth × Width × Height 670mm*433mm*87.6mm |
| Weight (Not Including Hard Drive) | ≤ 25kg |
| Case Type | Imported SGCC (galvanized steel plate) ABS panel and punching mesh, hot-swappable hard drive rack |
| System Configuration | |
| Storage Mode | Supports two modes:The default standard storage server mode and the other is Fusion Cloud storage server mode; |
| Standard storage server mode: general network storage services, such as IPSAN/NFS, can be used by other platforms (Hikvision, Dahua, Uniview, etc.); | |
| Fusion Cloud Storage Server Mode: It can be used as a slave server of Fusion Cloud (only media forwarding and storage services are deployed) and can be used in combination with Fusion Cloud platform server. | |
| Storage Capability | Supports 36-slot data storage.Supports media forwarding + video storage sharing 850M (can also be used independently in a single scene) |
JVS-VS6836-S 36-Bay Video Storage Server – 720TB RAID & 850M Write Speed
Product Overview
The JVS-VS6836-S 36HDD Video Storage Server is engineered for massive surveillance data:
-
Unmatched Capacity:
✓ 36 hot-swappable bays (2.5″/3.5″)
✓ 720TB raw storage (20TB/drive) -
High-Speed Performance:
✓ 850MB/s sustained write speed
✓ DDR4 RAM (16GB expandable to 32GB) -
Enterprise RAID Support:
✓ RAID 0/50/60 + JBOD
✓ Faulty disk auto-removal -
Industrial Reliability:
✓ EMI-shielded chassis
✓ Intelligent cooling (25dB noise)
✓ -5°C~45°C operation -
Smart Features:
✓ Network auto-reconnect
✓ Disk failure alerts
Best for: Data centers, smart city projects, and airports needing long-term, high-availability video archives.
