| Detection Distance |
| Day |
5Km |
| Night |
3Km |
| Visible Imaging |
| Sensor Type |
1/1.8 “target starlight CMOS, integrated ICR dual filter day and night switching |
| Minimum Illumination |
Color: 0.0005Lux;Black & White: 0.0001Lux; 0Lux (IRON) |
| Lens |
12.5 ~ 775mm HD motorized zoom;Manual/auto focus, 3A adaptive active focus algorithm, supports multiple trigger modes, accurate and high-speed |
| Zoom |
62x Optical Zoom |
| Image Processing |
Supports White balance, electronic shutter, Frame accumulation, BLC, HLC, 2D/3D DNR, Electronic image stabilization, WDR |
| Day and Night |
0.4 ~ 0.75μm visible light wide spectral window and 0.8 ~ 0.95μm near-infrared spectral window. Day and night independent double clear light window, improve the signal-to-noise ratio of imaging light and stray light |
| Defog |
Support digital defog, Optical defog |
| Laser Light Source |
| Wavelength |
810nm military grade infrared laser |
| Illumination Angle |
0.5° ~ 20° |
| Laser Safety |
Adopt ZQB safety laser beam processing patented technology, in line with international IEC 60825 safety standards |
| Encapsulation |
The luminous body is filled with inert gas and sealed to prevent oxidation |
| Lens Form |
60x f1.2～80mm ultra-short-focus zoom patent technology, laser 600μm cross-section imaging lens |
| Transmittance |
Coated with multi-layer near-infrared anti-reflection coating, high-efficiency laser coupling |
| Synchronous Control |
DSS digital stepping lighting angle control technology, 0.1° precise follow-up control, automatic tracking or manual fine-tuning intelligent matching method |
| Synchronization Effect |
The laser synchronization effect adjusts the modes of in-cut, outer-cut, full-screen coverage, etc., and can be set arbitrarily according to the scene remotely |
| Optical Axis Alignment |
SLM dual optical axis electric self-locking alignment device, the accuracy can reach 0.01° |
| Power |
15W |
| Audio & Video |
| Image Resolution |
2688×1520；1920×1080；1280×1024；1280×960；1024×768；1280×720；704×576；640×512；640×480；400×300；384×288；352×288；352×240 |
| Video Encoding |
H.265/H.264/MJPEG, Support multi-stream |
| Video Bitrate |
32Kbps ~ 16Mbps |
| Audio Codec |
G.711A / G.711U/ G726 |
| Image Flip |
Left/ Right/ Up/ Down/ Diagonal |
| OSD Settings |
Support OSD display settings of channel name, time, PTZ orientation, field of view angle, focal length, and support preset name setting. |
| Enhancements |
| Ranging |
Support passive ranging |
| Camera Diagnosis |
Support network disconnection alarm, support IP conflict alarm, support illegal access alarm, support SD card abnormal alarm, video blocking alarm |
| Laser Setting |
Support electric alignment adjustment, pan and tilt speed can be set, and motor status can be obtained; support laser synchronization, optional laser spot incision, outer incision, full screen; support manual adjustment of laser aperture |
| Resume Upload |
Support |
| Power-off Memory |
Support to restore the position before power-off, preset position status, cruise status, line scan status |
| Remote Maintenance |
With fault query, self-check, remote restart functions; online upgrade, remote upgrade |
| Configuration File |
Support configuration file import and export functions |
| PTZ |
| Range |
Pan 0°~360°, Tilt -45° ~ +45° |
| Rotational Speed |
Horizontal 0.01°/Sec ~ 30°/Sec, Vertical 0.01°/S ~ 15°/Sec, Support lens focal length speed adaptive function |
| Preset Cruise |
255 presets, support 6 cruise routes |
| Watch |
Preset position/pattern scan/cruise scan |
| Memory |
Support (Can restore the position before power-off, preset position status, cruise status, line scan status) |
| Zero-point Correction |
Support the north zero-point remote correction function |
| Wipers |
Support |
| Network |
| Interface |
1x RJ 45, 10/100 Base-T adaptive |
| Protocols |
2 Protocol: Support TCP/IP, UDP, IPv4/v6; Supports HTTP, RTP, RTSP, NFS, DHCP, NTP, SMTP, SNMPv1/v2c/v3, UPNP, PPPoE, DNS, and FTP. Supports network protocols such as ONVIF2.0 and GB28181 |
| General |
| Power Supply |
DC 24V, |
| Power Consumption |
≤180W |
| Working Temperature |
-40°C ~ +60°C |
| Storage Temperature |
-45°C ~ +70°C |
| Humidity |
<95%Rh |
| Lightning Protection |
Built-in surge protection 6000V |
| Anti-salt Spray |
PH value of 6.5 to 7.2, continuous spraying for 96 hours |
| Ingress Protection |
IP66 |
| Structure Material |
Split design, the whole adopts high-strength aluminum alloy material |
| Weight |
45Kg (Including the mount) |
